Automatic form fill sealing vffs powder packing machine with auger
filler for 1-5000g/bag
How do vertical form/fill/seal VFFS packaging machines work?
A vertical form fill seal machine, also known as a VFFS, is a
common bagging machine used to package goods into bags as part of a
production line. Just as the name suggests, this machine starts by
helping to form the bag from roll stock. Then, the bag is filled
with product and sealed in preparation for shipment.
Technical features:
Multi language interface, easy to understand.
Stable and reliable PLC program system.
Can store 10 recipes
Servo film pulling system with accurate positioning.
Vertical and horizontal sealing temperature is controllable,
suitable for all kinds of films.
Various packaging styles.
Synchronization of filling, bag making, sealing and coding.
Technical parameters:
| Model | DCS-520 |
| Length of bag | 50-390mm(L) |
| Width of bag | 50-250mm(W) |
| Width of film | 520mm |
| Packing speed | 15-60bag/min |
| Air pressure | 0.65mpa |
| Air consumption | 0.3m³/min |
| Power supply | 220VAC/50/60Hz |
| Power | 2.2KW |
| Dimension | 1080(L) ×1500(W) ×1600(H)mm |
| Weight | 650Kg |
About us
Wuxi Jianlong Packaging Co., Ltd. is a R & D and production
enterprise specializing in solid material packaging solution. Our
product portfolio includes bagging scales and feeders, open mouth
bagging machines, valve bag fillers, jumbo bag filling machine,
automatic packing palletizing plant, vacuum packaging equipment,
robotic and conventional palletizers, stretch wrappers,
conveyors,telescopic chute, flow meters, etc.
Wuxi Jianlong has a group of engineers with strong technical
strength and rich practical experience, which can help customers
with one-stop service from solution design to product delivery,
freeing workers from the heavy or unfriendly working environment,
improving production efficiency, and will also create considerable
economic returns for customers.
Wuxi Jianlong offers a wide range of knowledge about packaging
machines and related ancillary equipment, bags and products, as
well as packaging automation solutions. Through the careful testing
of our professional technology and R & D team, we are committed to
providing perfect customized solutions for every customer. We
combine the international quality with the Chinese local market to
provide an ideal automatic / semi-automatic, environmental friendly
and efficient automatic packaging system. We are constantly
striving to provide customers with intelligent, clean and
economical packaging equipment and industrial 4.0 solutions by
combining rapid localization service and spare parts delivery.
No matter what solutions we offer you, such as material
characteristic analysis, packaging bag analysis or feeding,
conveying, filling, packaging, palletizing, automatic design and
turnkey engineering, we are looking forward to be your reliable
long-term partner.
